高端32位MCU


	Device Name	CX3288AGL64C	CX3288AGL100C	CX3288AEL144C	CX3288AEL176C	CX3288AEB292C	CX3288ADB480C	CX3288ARL100C
	Target Market	Automotive General	Automotive General	Automotive Enhanced	Automotive Enhanced	Automotive Enhanced	Automotive Enhanced	Automotive Reliability
System	Core	RISC-V core up to 240MHz	RISC-V core up to 240MHz	RISC-V core up to 300MHz	RISC-V core up to 300MHz	RISC-V core up to 300MHz	RISC-V dual-core up to 300MHz	RISC-V core up to 240MHz
System	Ambient temperature (Ta)	-40℃ to 125℃	-40℃ to 125℃	-40℃ to 125℃	-40℃ to 125℃	-40℃ to 125℃	-40℃ to 125℃	‘-40℃ to 150℃
Memory	Flash	1MB	1MB	2MB	2MB	2MB	4MB	1MB
	Emulated EEPROM	64KB-512KB	64KB-512KB	64KB-1MB	64KB-1MB	1MB	1MB	64KB-512KB
	I/D Cache	8KB/8KB	8KB/8KB	8KB/8KB	8KB/8KB	8KB/8KB	8KB/8KB per core	8KB/8KB
	SPI FLASH	No	No	Yes	Yes	Yes	Yes	No
	PSRAM	No	No	Yes	Yes	Yes	Yes	No
	SRAM	128KB+32KB	128KB+32KB	256KB+64KB	256KB+64KB	256KB+64KB	512KB+128KB	128KB+32KB
Communication	UART	2x	2x	4x	6x	12x	12x	2x
	LIN	4x	4x	6x	6x	6x	12x	4x
	CAN	4x	4x	6x	6x	6x	12x	4x
	Ethernet	No	No	1x	1x	1x	2x	No
	I2C	2x	2x	4x	4x	4x	8x	2x
	SPI	4x	4x	6x	6x	6x	12x	4x
IO	GPIO	46	82	126	158	220	420	82
Analog	12-bit DAC	1x	1x	1x	1x	1x	2x	1x
Analog	12-bit ADC	20 channel	32 channel	38 channel	42 channel	42 channel	84 channel	32 channel
Timer	Low Power Interrupt Timer (LPIT)	1x	1x	2x	2x	2x	4x	1x
	SPWM	2x	2x	4x	4x	4x	8x	2x
	MPWM	2x	2x	4x	4x	4x	8x	2x
	Low Power Timer (LPTMR)	1x	1x	2x	2x	2x	4x	1x
	Real Time Counter (RTC)	1x	1x	1x	1x	1x	1x	1x
Other	Security	HSM	HSM	HSM	HSM	HSM+	HSM+	HSM
	Standard	AEC-Q100 Grade1/	AEC-Q100 Grade1/	AEC-Q100 Grade1/	AEC-Q100 Grade1/	AEC-Q100 Grade1/	AEC-Q100 Grade1/	AEC-Q100 Grade0/
		ASIL-B/	ASIL-B/	ASIL-B/	ASIL-B/	ASIL-B/	ASIL-C/	ASIL-C/
		EVITA light	EVITA light	EVITA light	EVITA light	EVITA light	EVITA light	EVITA light
	Packages	LQFP 64	LQFP 100	LQFP 144	LQFP 176	BGA292	BGA480	LQFP 100
备注：也有类似的工业级产品可以提供，主频可以高达420MHz，工作温度-40℃ to 105℃。
